Performance characteristics
All parts in contact with materials of the machine are made of stainless steel, with beautiful appearance, reasonable structure, high granulation forming rate, beautiful particles, automatic discharge, avoiding particle damage caused by manual discharge, and suitable for flow operation.
Scope of application
This machine is used in pharmaceutical, food, granule, chemical, solid beverage and other industries to make the required granules from the stirred materials, especially for the materials with high viscosity.
| Grinding knife size(mm) | ZLB-250 | ZLB-300B | ZLB-300D |
| Particle diameter（mm） | Φ2-2.2 （According to user needs） | Φ1.2-3 （According to user needs） | Φ0.5-6 （According to user needs） |
| Overall dimension（mm） | 700×540×1300 | 880×640×1300 | 1300×800×1200 |
| Motor power（kw） | 3 | 4 | 7.5-6 |
| Weight（kg） | 350 | 400 | 780 |
Productive power（kg/h） | 100-200 | 140-400 | 300-600 |
Note: Due to material differences, the output in the table is for reference only
